| ITEM |
UNIT |
20 |
20A |
| Max. turning dia. of main spindle |
mm |
20 |
20 |
| Max. turning dia. of sub spindle |
mm |
- |
- |
| Max turning length (Fixed guide bush) |
mm |
200 |
200 |
| Max. turning length (Rotary guide bush) |
mm |
85 (optional:150) |
85 (optional:150) |
| Max. turning length (Non guide bush) |
mm |
45 |
45 |
| Max. drilling capacity of main spindle |
mm |
10 |
10 |
| Max. drilling capacity of sub spindle |
mm |
- |
- |
| Max. tapping capacity of main spindle |
|
M8 |
M8 |
| Max. tapping capacity of sub spindle |
|
- |
- |
| Max. cross drilling capacity |
mm |
- |
10 |
| Max. cross tapping capacity |
|
- |
M6 |
| No. of external turning tools |
pcs |
12 |
8 |
| No. of internal turning tools |
pcs |
5 |
5 |
| No. of cross drillings |
pcs |
- |
4 (optional:7) |
| Face tool holder (Sub~spindle) |
pcs |
- |
- |
| Size of tool |
mm |
12x12x90 |
12x12x90 |
| No. of axis controls |
|
3 (X/Y/Z) |
4 (X/Y/Z/C) |
| Bore of spindle |
mm |
29 |
29 |
| Spindle speed range |
rpm |
200~8000 |
200~8000 |
| Rapid traverse X / Z |
m/min |
24 |
24 |
| Main spindle motor |
kw |
3.7 |
3.7 |
| Sub spindle motor |
kw |
- |
- |
| X1 / Z1 motor |
kw |
0.5 / 0.75 |
0.5 / 0.75 |
| Y-Axis motor |
kw |
0.75 |
0.75 |
| Cross drilling motor |
kw |
- |
0.5 |
| End drilling motor |
kw |
- |
- |
| X2 / Z2 motor |
mm |
- |
- |
| Coolant motor |
kw |
0.375 |
0.375 |
| Power Requirement |
kw |
10 KVA |
10 KVA |
| Machine dimensions |
mm |
2015x1040x2210 |
2015x1040x2210 |
| Weight |
kg |
1800 |
1800 |
