Manford VL-2090 Vertical Machining Center

Homepage / Manford VL-2090 Vertical Machining Center

X Axis — 2,000 mm

Y Axis — 900 mm

Z Axis — 850 mm

Spindle Speed — 8,000 rpm

Spindle Taper — BT40

SPECIFICATION
X TRAVEL	2,000 mm
Y TRAVEL	900 mm
Z TRAVEL	850 mm
SPINDLE NOSE TO TABLE SURFACE	150 ~ 1,000 mm
TABLE SIZE	2,200 x 850 mm
T-SLOT (Q'TY X SIZE X DIST)	5 x 22 x 150 mm
MAX. TABLE LOAD	2,000 kgs
CNC CONTROL	Mitsubishi / Fanuc / Siemens / Heidenhain / Fagor
SPINDLE
SPINDLE TRANSMISSION	Belt type
SPINDLE TAPER	BT40 / BT50
SPINDLE SPEED	BT40：8,000 rpm / BT50：6,000 rpm
SPINDLE MOTOR	7.5 / 11 kW
OTHER ITEMS
ATC CAPACITY	ATC Genoa type 20 tools / Arm type 24 tools
